T5 LED Tube Light
High light efficiency: 112-120lm / W, 10W for 30W, saving 2/3, easy to maintain
High-profile high-quality: high-profile Taiwan wafer large chip 2835 lamp beads 0.2w 60mA, 1.2mm thick high thermal conductivity aluminum substrate, power conversion efficiency 92% high efficiency anti-lightning constant current drive, low heat, 12000 hours / 105 ℃ electrolytic capacitor The
High brightness: light efficiency up to 110lm / W or more, is the same power brightness and ordinary T5 integrated fluorescent lamp bracket brightness of 3 times; 10W can replace the ordinary 28W 1.2 m T5 fluorescent lamp!
Super power: saving more than 65%, each lamp a year to save 48 yuan (300 days) 5 years province 240 yuan, T5led lamp costs ignored.
Long life: the use of long life, 12000 hours / 105 ℃ high temperature long life electrolytic capacitors, a installation, life of more than 5 years. 85 degrees working conditions 36000 hours / 85 ℃
T5 LED Tube adopt super bright SMD3528 LED Bulb chip and brings out more lumens. This amazing T5 LED Tube Light is a replacement for traditional T8 fluorescent tubes allowing you to bring LED technology to environments, save over 80% electricity cost.
| Size | 300mm (1feet) | 600mm (2feet) | 900mm (3feet) | 1200mm (4feet) | |||||||||||
| Power | 3W | 4W | 5W | 7W | 8W | 10W | 8W | 11W | 15W | 8W | 14W | 15W | 16W | 18W | 20W |
T5 LED Tube Lighting
14W T5 LED Tubes Replace 38W T5 fluorescent tubes(no need starter and ballast)
T5 LED Tube light 4FT 14W Parameter
| Model | LT-T5-14W |
| Power | 14 W |
| Size | Φ16 * 1.2M (4FT) |
| LEDQty | 224 * SMD3528 |
| LM | 1344LM |
| Cover | Transparent/Frosted/Strip |
| Material | Aluminium alloy + PC |
| Input voltage | 100-277VAC |
| Frequency | 50-60Hz |
| Beam Angle | 120deg |
| CRI | Ra>80 |
| Lifetime | 50000 hrs |
| Environment | -20 ~ +45°C |
| Material | Aluminium alloy + PC |
| Color | Warm white/Natural White/ Pure White/Cool White |
T5 LED Tube led tube light Cover
1. Stripe cover
2. Transparent cover let can be seen from the front (brightest light output)
3. Frosted cover vivid light effect exactly same as CFL
Color temperature: 2700-7000K
T5 LED Tube Feature
1. Rotating End Cap: The facility on tubes allows directional lighting to fully optimise product display.
2. Energy saving: saving 80% energy over conventional fluorescent lamps.
3. Replace fluorescent lamp directly.
4. Long lifespan: 50,000 hrs lifespan, 3 time longer than fluorescent lamp, low maintenance cost.
5. Vibration-proof, no flickering.
6. No hazard of mercury or lead entering the environment
7. No danger of broken glass
T5 LED Tube Packing
T5 LED Tube Component
1. Power Supply
2. PC cover top case
3. Aluminum plate Light board
4. Aluminum groove bottom case
5. LED Bulb chip
.jpg)
T5 LED Tube Spectrum report
T5 LED Tube Application
1. Offices
2. Shopping malls
3. Library
4. Exhibition Gallery
5. Factories
6. Closet
7. Recreation application
